Locate the pressure sensor and locate the white wire and the g post. All sensors are standard ground sensors case to common ground.
Oil Pressure Sending Unit Wiring Question Pelican Parts Forums
Vdo oil pressure sender wiring. Vdo pressure senders may not be used in automotive braking systems. Do not deviate from assembly or. This will interfere with grounding causing incorrect instrument readings. 150 psi10 bar oil pressure gauge use with vdo sender 12v 250 spade connection learn more viewline ivory 150 psi10 bar gauge 1224v sender kit with us thread adapters. 158 or equivalent 1 4. Vdo pressure senders are not to be used with any type of fuel application.
Repair service for oem instrument clusters and systems merri mcintyre phone. Pressure sender 100 psi 18 27npt 0 90 ohm ac learn more. Temperature pressure or fuel gauge 2⁵₈ 66 mm diameter 1 2. Vdo senders have tapered threads and do not require the use of teflon tape or pipe sealant. Installation instructions 1 caution. Light bulb 12 volt ge.
I installed the vdo oil pressure and temperature gauges in my 1970 vw but will give you the concept on installing them in any vehicle. The fuel sender should show between 10 and 180 ohms depending on how much fuel is in the tank. Repair service for aftermarket gauges and accessories connie heflin phone. Read these instructions thoroughly before making installation. Viewline onyx 80 psi5 bar oil pressure gauge 1224v with vdo sender and metric thread adapters add to compare. Disconnect the negative wire.
Sensors are matched to gauges according to maximum reading on dial face. Afterwards connect the green wire on the oil pressure gauge to the sensors g post. Vdo spin lok clamp or mounting bracket 1 5. Test your vdo fuel sender with a multimeter. All pressure sensors are designed to work with vdo gauges only unless otherwise noted. 150psi10bar 0 5v m12x15 add to compare.
Disconnect the fuel sender positive wire from the fuel gauge. Vdo senders have tapered threads and do not require the use of teflon tape or pipe sealant. Lamp socket push in wedge type 1 3. This is part 1 on how to install vdo gauges. Connect the white wire on the sensor to the white wire on the gauge. Touch the negative lead of the multimeter to the negative wire and the positive lead to the positive wire.
Step 5 connect the black wire.
