Install single pole dimmer switch. Standard single pole switches do not. The ground screw is for the circuit ground wire connection. Check for hot wires. Installation is a simple matter of connecting the hot wire leads to the hot circuit wiresone of which is entering the box from the power source the other leading to the light fixture. Everything home tv hosted by. Connect the ground green wire on the switch with the ground green label wire from the wall.
Installing a 3 way lutron dimmer on a single pole application. Item 3 lutron dimmer single pole3 way 120 v ivory lutron dimmer single pole3 way 120 v ivory. Kasa smart dimmer switch by tp link single pole needs neutral wire wifi light switch for led lights works with alexa and google assistant ul certified 3 packhs220p3 46 out of 5 stars 300 6999. Since this is only single pole and not 3 way i dont need one of the red wires so i should cap it off. Close posted by 1 hour ago. Connect the second lineload black wire on the switch to the line or load black label wire from the wall.
There are several types of dimmer switches out there. Dimming your lights can cut down on your electricity costs. The other terminal is for a second hot wire called a switch leg that runs only between the switch and the light fixture. Traditional single pole dimmer switches like standard switches generally have just two hot wires and a ground wire with no neutral wire connection. However on my switch the 2 red wires are solid. Cap the 3 waymulti way traveler wire if applicable.
This dimmer can replace any decorator style switch or dimmer. We show the single switch but there are also. Item 4 lutron dimmer single pole3 way 120 v white lutron dimmer single pole3 way. Installing a 3 way lutron dimmer on a single pole application. My problem is lutron says to cap off the red wire with the white stripe. Turn on the light and have.
How to install a dimmer switch choosing a dimmer. To begin turn off the power and double check for hot wires in the box. If youre installing a 3 way click here for instructions. Coming out of the switch itself is 2 red wires a black wire and a ground wire. They have two screw terminals plus a ground screw. Brian domingo visit us online at.
Dimmer features a slide to off mechanism. Item 2 lutron diva cl dimmer switch dvwcl 153ph wh white cflled with wall plate lutron diva cl dimmer switch dvwcl 153ph wh white cflled with wall plate. Single pole switches are the most common light switches in a home. No stripes of any color on. One screw terminal is for the hot wire that feeds the switch from the power source. Slide up to turn onbrighten slide down to turn offdim.
Item 1 lutron maestro cl dimmer switch for dimmable led lutron maestro cl dimmer switch for dimmable led. For single pole applications where lights are controlled from 1 location. Works with existing multi gang decorator wall plates. The switch leg brings power to the fixture when the switch is turned on.
