Connect the other end of the green wire to the. Follow the relays wiring schematic when connecting the wires to the relay one of the relays terminals goes to ground.
How To Install Your Own Driving Lights Off Road Driving Lights
How to wire driving lights using a relay. How to wire aux lights fog lights led lights light bar or anything else to a switched circuit in your vehicle the right way. Scotch lock the bare end of the green wire to the low or high beam lead. Ive been doing all my own wiring as i couldnt find a suitable harness heres what ive done so far. The line you spliced off your high beam wire or your backup light wire. How to wire your light using a relay. The switch included gives more flexibility controlling the lights.
De stickers on etsy. Harness wiring locate the low beam or high beam light lead on one headlamp by using a circuit tester. This listing is features one set new relay wiring harness with onoff switch universal fit for led daytime running lights off road driving lights and led work lights. The switch will activate the driving lights when you turn on. Route the power supply wire the power supply wire will run from the high beam relay wiring harness to the driving or fog lights. 30 and 87 create the switch to your lights.
My project for the long weekend was to wire up a lightbar on my ve ute i was able to get everything to work except the turning on and off with the highbeams part. To fit your new lights follow these steps. In this case you need to wire the dash switch in between the trigger current ie. Find a suitable place on your dashboard for the switch. How to install driving lights overview. Fog light driving light daytime light.
Run a. Want to support de. Do not connect the power to the battery until all wiring is done. Then run a heavy gauge wire from the battery to the relay placing a 30 amp fuse in line very close to the battery. 30 is your power source for your light. 1 x relay switch control wiring harness.
Start by taping one end of the power wire to the metal bumper support. Mount the relay in the engine bay placing it as close to the battery as possible while avoiding areas of excessive. It connects to the. The relay will have 4 points on it marked 30 87 85 and 86. That is kind of cryptic isnt it. With our wiring harness all you need to do is cut the wire coming from the switch to the 30 prong on the relay and wire it to your high beam lead or your backup light wire.
By default this switch is open so the current cannot get from the battery to your lights. Use the following procedure. Attach the black wires from the lamps. The left side is the pin out of the point is sticking out from at the bottom and the the right side is showing a schematic representation of the relay circuitry. Leave at least one foot of wire hanging after the tape to leave enough slack for the connection to the lights.
