How to wire a hunter ceiling fan and light control. Connect the three grounding wires green greenyellow stripe or bare copper coming from the ceiling fan rated electrical box the downrod attached to your fan and the ceiling bracket. Connect the white wire from the ceiling to the white wire from the fan. Hunters universal wall control works up to a 75 foot range and is compatible with any brand of ceiling fan. Connect the black wire from the fan to the yellow wire from the receiver. Wiring the hunter ceiling fan model number 21871. Installation wiring installation wiring.
Use a wire nut to connect each of the following. In order for the light to be controlled by its own switch the wiring between the switch and the fan unit needs a fourth wire a red wire to carry power to the light kit. Works with ceiling fan motors up to 1 amp and light kits up to 300 w. Installation mounting options. The blue wire connects to the wire for the ceiling fan. The red wire and the gray wire connect to the fan motor starting coil.
The blue wire is for the fan light power. The pink wire and the yellow wire connect to the primary coil of the fan motor. What tools do i need in order to install a ceiling fan. What do i need to install my ceiling fan on an angled ceiling. Connect the ground wire from the ceiling fan often this is connected to the fans hanger bracket to the circuit ground wire and to the electrical box if it is metal using a pigtail wire to connect to the box. The red wire connects to the wire for the light of the ceiling fan.
Connect the black wire from the ceiling to the black wire from the fan. Connect the blue wire from the fan to the blue wire from the receiver. Join the three wires with an appropriately sized wire connector. Cap the blue wire coming from the fan by itself with a wire nut as it is not needed when wiring for a single wall switch. David from the information you have providedthe hunter model 27182 dimmer fan control switch is wired as follows. My ceiling fan came without a light fixture.
Connect your white wires together and secure with wire nut. Helpful information about wiring mounting options downrods and more. Connect the green wire to your household ground wire copperbare wire. Damp rated for use as an indoor or outdoor ceiling fan in spaces exposed to moisture and humidity such as porches patios sunrooms and bathrooms. The wiring designations for this hunter ceiling fan are as follows. Connect the three white wires from the ceiling fan and receiver together.
The black wire is connected to the hot or power supply. The white wire is for the fan light. Connect the black wire from the ceiling to the black wire from the receiver.
